EMG Finger Exerciser Low Frequency Therapy Device


Product Introduction


H1 Hand Rehab System is the first wearable hand rehabilitation device based on iOS. H1 combines biofeedback sEMG, Neuromuscular Electrical Stimulation (NMES), EMG Triggered Stimulation (ETS), Power Assistant Stimulation (PAS) and integrated electrode, providing perfect user experience for medical personnel and patients.


Innovations

• Collection and processing technology of patient’s EMG signals
• Latest generation of real-time Power Assistant Stimulation based on EMG
• A combination of biofeedback interactive games and rehabilitation training based on EMG
• Multiple training modes in Rehabilitation APP

Mode Selection
NMES Mode: Under this mode, user can download different prescriptions from APP for different needs.
ETS Mode: Under this mode, user can set up a threshold by the APP. The stimulation will be triggered when the EMG signal reaches the threshold.
PAS Mode: User can set up a threshold by the APP, the stimulation will be triggered when the EMG signal reaches the threshold and will continue as long as the signal is above the threshold.
EMG Mode: Under this mode, the stimulator will detect user's sEMG signal. After you follow the instruction of 3-second relax and 6-seccond measuring cycle for 3 times, the stimulation will display the average value, and the average will be set as the threshold in ETS and PAS.

GAME Mode: This mode combines rehabilitation and games. The stimulator transits the EMG signals to the APP via Bluetooth. The APP controls the speed and position of the games according to the signals. It improves the rehabilitation level and strengthens patient’s motivation of training.


Specification

Product name	H1 Hand Rehab System
Model	XFT-2003E
Classification	Type BF Equipment
Power supply	Rechargeable lithium battery 7.4V
Maximum Current	250mA
Max Voltage	30 V
Pulse Width	50 ~ 450μs (±10%)
Frequency	2 ~ 100Hz (±10%)
Wave form	Asymmetrical balanced biphasic wave
Size	140*58*27mm
Weight	120g
Service life	5 years

Warranty
All XFT products are provided with 2-year warranty starting from the date of purchasing.


XFT Company Information
We are an ISO9001 & ISO13485 qualified manufacturer specialize in providing healthcare products, rehabilitation products and first aid training products for more than 19 years. Nearly all of our products got CE, ROHS certification and FDA registration. We export our products to all over the world.


XFT Company Photos

Medical Fairs

We have attended many medical fairs every year, such as:
-- Medica
-- FIME
-- HKTDC
-- CMEF
-- WCPT
-- ISPRM

Our Service

1. Professional manufacturer.

2. OEM/ODM service is available:
1) Customized logo on the products
2) Re-design the package
3) Customized function or outlook of the prdoduct
4) Any your idea on product we can help you to design and put it into production

3. High quality, fashion designs, reasonable & competitive price, fast lead time.

4. After-sale service:
1) All products will be strictly Quality Checked before packing
2) All products will be well packed before shipping
3) All our products have 1 year warranty.

5. Faster delivery:
Sample order will be delivered in 1-3 days , large quantity will be delivered in 5-12 days.

6. Payment:
You can pay for the order via: T/T; Western Union & PayPal.

7. Shipping
We have strong cooperation with DHL, TNT, UPS, FEDEX, EMS, China Air Post.
You also can choose your own shipping forwarder.

Founded in 2000 and headquartered in China, XFT is a company which combines development and manufacture with advanced technology. From the past 19 years to now, XFT has taken these efforts and created a pioneering brand leading the way in high quality personal medical rehabilitation products with affordable price.

By improving innovative technology to launch hi-tech and emerging products, we believe that technology can help people in an effective and convenient therapy anywhere at any time while evolving to fit your daily lifestyle.

XFT is a qualified medical brand offering intelligent medical products and accessories such as Foot Drop System, Hand Rehab System, sEMG Biofeedback FES Device, Pelvic Muscle Trainer etc.. ISO13485, CE, FDA certificated, XFT has become a trustworthy brand in the industry. Today, XFT manufactures and delivers wearable and smart products to people worldwide.

All of our products are based on solutions from our customers. We enjoy contacting our customers efficient and fast. When you email or call us, you will get real people who care about XFT products and are standby to providing you with outstanding service. For our latest news, be sure to email us at xft@xft.cn or call us 86-755-29888818.
