XFT-2001D is a functional electrical stimulation (FES) or Neuro Rehabilitation device for the treatment of foot drop or Dropped Foot caused by Brain or Spinal diseases or Trauma, such as Stroke (CVA), Multiple Sclerosis (MS), Spinal Cord Injury, Traumatic Brain Injury (TBI), Brain Tumor, or Cerebral Palsy (CP). The XFT-2001D Foot Drop System is intended to provide ankle dorsiflexion in individuals with foot drop.
XFT-2001D Foot Drop System utilizes intelli-sensor technology and functional electrical stimulation (FES) to analyze the movement of the leg and stimulate the appropriate nerves, prompting the foot to lift with every step.
Stimulation causes the foot to lift (dorsiflexion) and tilt slightly (eversion). Stimulation also can be timed to walking by using a pressure switch placed in the shoe under the heel. Stimulation begins when the heel is lifted from the ground and ends just after heel strike. Stimulation causes the foot to lift and stabilises the ankle when the foot is returned to the ground.
| Product name | Hemiplegia MS Walking Assist Fes Device foot drop system |
| Model | XFT-2001D |
| Classification | Type BF Equipment |
| Power supply | DC3.7V, rechargeable lithium battery |
| Maximum Current | 90 mA |
| Max Voltage | 90 V |
| Pulse Width | 100-300 microseconds (±10%) |
| Frequency | 16.7-40 Hz (±10%) |
| Wave form | Asymmetrical balanced biphasic wave |
| Size | 75 x 70 x 10mm |
| Weight | 43 g |
| Service life | 5 years |
Functional electrical stimulation (FES) is a technique that uses electrical currents to activate nerves innervating extremities affected by paralysis resulting from spinal cord injury (SCI), head injury, stroke and other neurological disorders. FES is primarily used to restore function in people with disabilities. It is sometimes referred to as Neuromuscular electrical stimulation (NMES) The latest treatments include stimulation of the peroneal nerve, which lifts the foot when you step. Many stroke and multiple sclerosis patients with foot drop have had success with it.
Regular use of the Foot Drop System XFT-2001D will achieve great benefit:
- Improve ground clearance;
- Reduce tripping and falls;
- Reduce compensatory movements such as hip hitching or
circumduction (swing the leg out side ways);
- Reduce effort of walking;
- Reduce spasticity in the calf and quadriceps muscle;
- Increase walking speed;
- Heel strike with eversion;
- Improve the position of the foot in weight bearing resulting in greater stability in stance;
- Greater walking range of mobility;
- Greater safety, confidence and independence while walking;
- Long term therapeutic benefit resulting in improve unaided walk .
• Two modes: gait and training
• Small and compact
• Easy operation (one-hand operation)
• One-time accurate electrode positioning
• Voluntary control and increase joint range of motion
• Advanced accelerometer to analyze the movement and stimulate the
appropriate nerves
• Three comfortable sizes to choose
Foot Drop System XFT-2001D can be effective where movement has been
lost due to nerve injury / disease within the brain or spinal cord.
This is called an upper motor neuron lesion. If you are
experiencing foot drop (drop foot), paralysis or paresis as a
result of a Stroke, Multiple Sclerosis, Traumatic Brain Injury or
Spinal Cord Injury, you may benefit by using Foot Drop
SystemXFT-2001D. The Foot Drop System is also used by clinicians as
an FES tool for variety Neuro rehabilitation.
PLEASE NOTE: Foot Drop System XFT-2001D is not suitable for lower
motor neuron conditions. This is where the nerve that runs from the
spinal cord to the muscle is damaged. This is the case in
conditions such as:
Warranty:
All XFT products are provided with 2-year warranty starting from the date of purchasing.
