Watch video on: http://www.xft-china.com/?ac=article&at=read&did=49

1.What is Foot Drop System XFT-2001D?

Foot Drop Therapy System XFT-2001D is a single channel, tilt or foot sensor switch controlled neuromuscular stimulator designed to correct dropped foot. Self adhesive skin electrodes are placed on the side of the leg over a nerve called the common peroneal.

Stimulation causes the foot to lift (dorsiflexion) and tilt slightly (eversion). Stimulation also can be timed to walking by using a pressure switch placed in the shoe under the heel. Stimulation begins when the heel is lifted from the ground and ends just after heel strike. Stimulation causes the foot to lift and stabilises the ankle when the foot is returned to the ground.

3.Who can use Foot Drop Therapy System XFT-2001D?

Foot Drop Therapy System XFT-2001 can be effective where movement has been lost due to nerve injury / disease within the brain or spinal cord. This is called an upper motor neuron lesion. If you are experiencing foot drop (drop foot), paralysis or paresis as a result of a Stroke, Multiple Sclerosis, Traumatic Brain Injury or Spinal Cord Injury, you may benefit by using Foot Drop Therapy System XFT-2001. The Foot Drop Thrapy System is also used by clinicians as a FES tool for variety Neuro rehabilitation.

PLEASE NOTE: Foot Drop Therapy System XFT-2001D is not suitable for lower motor neuron conditions. This is where the nerve that runs from the spinal cord to the muscle is damaged. This is the case in conditions such as:

Peripheral nerve lesions

1. Poliomyelitis (Polio)
2. Motor neuron disease
3. Guillain-Barre syndrome

4. What benefit dropped foot patient can get from regular use of the Foot Drop System XFT-2001D?

• Improved ground clearance;
• Reduced tripping and falls;
• Reduced compensatory movements such as hip hitching or circumduction (swing the leg out side ways);
• Reduced effort of walking;
• Reduced spasticity in the calf and quadriceps muscle;
• Increased walking speed;
• Heel strike with eversion;
• Improves the position of the foot in weight bearing resulting in greater stability in stance;
• Greater walking range of mobility;
• Greater safety, confidence and independence while walking;
• Long term therapeutic benefit resulting in improved unaided walk .

5. Functions Illustrations

Specification:

Product name	Foot Drop System Rehabilitation Therapy Equipment
Model	XFT-2001D
Classification	Type BF Equipment
Power supply	DC3.7V, rechargeable lithium battery
Maximum Current	90 mA
Max Voltage	90 V
Pulse Width	100-300 microseconds (±10%)
Frequency	16.7-40 Hz (±10%)
Wave form	Asymmetrical balanced biphasic wave
Size	75 x 70 x 10mm
Weight	43 g
Service life	5 years

XFT Company Information

We are an ISO9001 & ISO13485 qualified manufacturer specialize in providing healthcare products, rehabilitation products and first aid training products for more than 19 years. Nearly all of our products got CE, ROHS certification and FDA registration. We export our products to all over the world.


XFT Company Photos

Medical Fairs

We have attended many medical fairs every year, such as:
-- Medica
-- FIME
-- HKTDC
-- CMEF
-- WCPT
-- ISPRM

Our Service

1. Professional manufacturer.

2. OEM/ODM service is available:
1) Customized logo on the products;
2) Re-design the package;
3) Customized function or outlook of the prdoduct;
4) Any your idea on product we can help you to design and put it into production.

3. High quality, fashion designs, reasonable & competitive price, fast lead time.

4. After-sale service:
1) All products will be strictly Quality Checked before packing;
2) All products will be well packed before shipping;
3) All our products have 1 year warranty.

5. Faster delivery:
Sample order will be delivered in 1-3 days , large quantity will be delivered in 5-20 days.

6. Payment:
You can pay for the order via: T/T.

7. Shipping
We have strong cooperation with DHL, TNT, UPS, FEDEX, EMS, China Air Post.
You also can choose your own shipping forwarder.

Founded in 2000 and headquartered in China, XFT is a company which combines development and manufacture with advanced technology. From the past 19 years to now, XFT has taken these efforts and created a pioneering brand leading the way in high quality personal medical rehabilitation products with affordable price.

By improving innovative technology to launch hi-tech and emerging products, we believe that technology can help people in an effective and convenient therapy anywhere at any time while evolving to fit your daily lifestyle.

XFT is a qualified medical brand offering intelligent medical products and accessories such as Foot Drop System, Hand Rehab System, sEMG Biofeedback FES Device, Pelvic Muscle Trainer etc.. ISO13485, CE, FDA certificated, XFT has become a trustworthy brand in the industry. Today, XFT manufactures and delivers wearable and smart products to people worldwide.

All of our products are based on solutions from our customers. We enjoy contacting our customers efficient and fast. When you email or call us, you will get real people who care about XFT products and are standby to providing you with outstanding service. For our latest news, be sure to email us at xft@xft.cn or call us 86-755-29888818.
